Unit Step

2 六月, 2016 - 15:17

The unit step function (Figure 2.4) is denoted by u (t), and is defined to be




media/image29.png
Figure 2.2 The complex exponential
Graphically, the complex exponential scribes a circle in the complex plane as time evolves. Its real and imaginary parts are sinusoids. The rate at which the signal goes around the circle is the frequency f and the time taken to go around is the period T . A fundamental relationship is T = f 1 .



media/image32.png
Figure 2.3 The real exponential.



media/image35.png
Figure 2.4 The unit step.



Caution: This signal is discontinuous at the origin. Its value at the origin need not be defined, and doesn't matter in signal theory.

This kind of signal is used to describe signals that "turn on" suddenly. For example, to mathematically represent turning on an oscillator, we can write it as the product of a sinusoid and a step: s (t)= Asin (2πft) u (t).
